The TL802 50A Relay 12V is a magnetic latching relay designed by Mingni tech for demanding applications such as smart meters, EV charging stations, and industrial power control. It features low power consumption, pulse drive activation, and strong reliability with magnetic arc extinguishing technology.
Key Features
- Rated current: 50A
- Coil voltage: 12VDC (available in 6V, 9V as well)
- Low power consumption with pulse drive
- High impact resistance and strong arc extinguishing capability
- Available in single-coil and double-coil configurations
- Electrical isolation: 4,000V between contact and coil
- CE and RoHS compliant
Technical Specifications
| Parameter | Value |
|---|---|
| Rated Load | 50A 250VAC / 50A 60VDC |
| Max Switching Voltage | 440VAC / 110VDC |
| Max Switching Power | 12,500 VA |
| Contact Resistance | ≤ 2 mΩ (12VDC 1A) |
| Insulation Resistance | ≥ 1,000 MΩ (DC 500V) |
| Dielectric Strength | Contacts to coil: AC 4,000V / 1 min |
| Mechanical Life | Over 1,000,000 cycles |
| Electrical Life | 100,000 cycles at 50A 250VAC |
| Operating Temperature | -40℃ to +70℃ |
| Humidity Range | 5% to 85% RH |
Applications
- Smart electricity meters
- Electric vehicle charging stations
- Special electric power devices
- Power supply modules
Dimensions
Size: 39mm × 30mm × 15mm
Certifications
- ISO9001
- ISO/TS16949
- ISO14001
- OHSAS18001
- IECQ QC 080000
For more information or to request a quote for the 50A Relay 12V, please contact us.
