TL313-150A Series High-Performance Single Coil Latching Relay
- Rated Current: 150A
- Coil Voltage Options: 6V, 9V, 12V, 24V DC
- Coil Types: Single Coil (L1) or Dual Coil (L2)
- Auxiliary Contact: Available or None
- Isolation: 4KV between contact and coil
- Drive Type: Pulse Drive
- Arc Extinguishing: Magnetic Technology
- Compliance: RoHS, CE, IEC62055-31
- Dimensions: 39.4mm x 22mm x 27.5mm
Product Overview
Product Features
- 150A contact segmentation capability with low power consumption
- Pulse drive operation for energy efficiency
- Strong impact resistance and high reliability
- Magnetic arc extinguishing technology
- Available in both single coil and dual coil configurations
- 4KV voltage withstand between contact and coil
- RoHS compliant and environmentally friendly
- Certified to IEC62055-31 UC3 and CE standards
- Compact design: 39.4mm × 22mm × 27.5mm
Product Specifications
| Parameter | Value |
|---|---|
| Rated Current | 150A |
| Coil Voltage | 6VDC, 9VDC, 12VDC, 24VDC |
| Contact Form | None (No auxiliary contact) / With auxiliary contact (Optional) |
| Coil Type | Single Coil (L1) / Dual Coil (L2) |
| Withstand Voltage (Contact to Coil) | 4KV |
| Dimensions | 39.4mm × 22mm × 27.5mm |
| Certifications | CE, RoHS, IEC62055-31 UC3 |
| Packaging | Plastic sealed type without solder resist (S-type) |
Key Parameters
- Rated Current: 150A
- Coil Voltage Options: 6V, 9V, 12V, 24V DC
- Coil Types: Single Coil (L1) or Dual Coil (L2)
- Auxiliary Contact: Available or None
- Isolation: 4KV between contact and coil
- Drive Type: Pulse Drive
- Arc Extinguishing: Magnetic Technology
- Compliance: RoHS, CE, IEC62055-31
- Dimensions: 39.4mm x 22mm x 27.5mm
Application Areas
The TL313-150A single coil latching relay is ideal for use in:
- Smart Energy Meters and Prepayment Systems
- Photovoltaic Inverters and Solar Power Systems
- Automotive Control Systems and EV Charging
- Industrial Automation and Machinery
- Power Supply and Distribution Systems
- Home Automation and Smart Appliances
- Telecommunication and Network Equipment
- Security and Alarm Systems
